Carbon Steel sheet used in an amount large class of materials,
divided into ordinary low-carbon steel and special steel
sheet,comprising
a high strength low alloy steel clad steel and corrosion resistant,
and the like. Ordinary low-carbon steel plates are divided into two
types:
cold-rolled and hot-rolled. Cold-rolled steel plates have good
surface quality and accurate thickness dimensions.
They are mostly used to make car bodies. Hot-rolled plates are
mostly used to make car frames and the like.
ASME SA 516 GR.70-55 Chemical Composition: |
Chemical Composition | Maximum C % for thickness t (mm) | | Si % | P % max | S % max |
6-12.5mm | 12.5-25mm | 25-50mm | >50mm | ≤12.5mm | >12.5mm |
ASME A516 Gr
55 | 0.18 | 0.2 | 0.22 | 0.25 | 0.55-0.98 | 0.60-1.30 | 0.13-0.45 | 0.035 | 0.035 |
ASME A516 Gr 60 | 0.21 | 0.23 | 0.23 | 0.25 | 0.6-0.9 | 0.80-1.20 | 0.13-0.45 | 0.035 | 0.035 |
ASME A516 Gr
65 | 0.24 | 0.26 | 0.26 | 0.28 | 0.85-1.20 | 0.85-1.20 | 0.13-0.45 | 0.035 | 0.035 |
ASME A516 Gr
70 | 0.27 | 0.28 | 0.28 | 0.3 | 0.85-1.20 | 0.85-1.20 | 0.13-0.45 | 0.035 | 0.035 |
ASME SA 516 GR.70-55 Mechanical Property: | ASTM A36 Hot Rolled Steel Plate |
Mechanical Property | Tensile
strength
(MPa) | Minimum
yield
strength
(MPa) | Minimum elongation (%) gauge length | Chemical Compostion | Mechanical Properties |
50mm | 200mm | Element | content | Mechanical Properties | Metric | Imperial |
ASME A516 Gr
55 | 380-515 | 205 | 27 | 23 | Carbon, C | 0.25 - 0.290 % | Tensile Strength, Ultimate | 400 - 550 MPa | 58000 - 79800 psi |
ASME A516 Gr 60 | 415 - 550 | 220 | 25 | 21 | Copper, Cu | 0.20% | Tensile Strength, Yield | 250 MPa | 36300 psi |
ASME A516 Gr
65 | 450 - 585 | 240 | 23 | 19 | Iron, Fe | 98.0% | Elongation at Break (in 200 mm) | 20.0% | 20.0% |
ASME A516 Gr
70 | 485 - 620 | 260 | 21 | 17 | Manganese, Mn | 1.03% | Elongation at Break (in 50 mm) | 23.0% | 23.0% |
| | | | | Phosphorous, P | 0.040% | Modulus of Elasticity | 200 GPa | 29000 ksi |
| | | | | Silicon, Si | 0.280% | Bulk Modulus (typical for steel) | 140 GPa | 20300 ksi |
| | | | | Sulfur, S | 0.050% | Poissons Ratio | 0.26 | 0.26 |
| | | | | | | Shear Modulus | 79.3 GPa | 11500 ksi |
products advantages
package:
Package | Standard export seaworthy package,suit for all kinds of transport,
or as required. |
Water-proof Paper + Edge protection + Wooden Pallets |
Bulk Size | Any size |
Loading Port | Tianjin, Xingang Port, Qingdao,Shanghai, Ningbo, or any China
Seaport |
Container | 1*20ft container load Max. 25 Ton, Max. length 5.8m |
1*40ft container load Max. 25 Ton, Max. Length 11.8m |
Delivery Time | 7-15 days or according to the order's quantity |
Shipping by 20 feet container, or 40 feet container or bulk vessel.
If quantity too small, we can shipping by LCL(less than container
to load)
Hot sales cold rolled mild steel sheet coils /mild carbon steel
plate/iron cold rolled steel sheet price
we have large stocks for the carbon steel and low alloy steel
plates and sheets, especially have the thick plate and heavy plates
on stock, also can provide the special material and large size
steel plates, boiler and pressure vessel steel plate, marine steel
plate, hot rolled steel plate for new production. Tianjin Emerson
Commercial and Trade Co., Ltd also has large stock for hollow bars,
thick wall seamless pipes and tubes. Tianjin Emerson Commercial and
Trade Co.,Ltd can provide good service for customer, good quality
products, fast delivery, and after-sale service, Tianjin Emerson
hopes to build good cooperation with everyone interested.
. How long will it take to execute my order?
A:Our normal lead time is 7-15 working days.,but we have many
models in stock,We will let you know the estimated lead time after
payment ASAP.
Q Can I have a sample for testing?
A: Free simples, you just need pay the freight.
Q. Do you have products in stock?
A: Because we only do wholesale, usually do not have stock, we
provide fast shipping for most products, If there is any stock, we
will inform you with details.
Q Do you have inspection procedures for the products?
A:100% self-inspection before packing
Q Can I have a visit to your factory before the order?
A: Sure,welcome to visit our factory.
